WE10...3X IR-Precision-Pressure-Regulator-118
Classification:Directional Control Valves

WE10...3X IR-Precision-Pressure-Regulator-118

Feature:
Get a Quote

Ordering Code

WE 10    -  3X/    □ □ /□

➊   ❷  ❸     ❹   ❺   ❻     ❼ ❽ ❾  ⓫ ⓬

Symbol Content
 3-Way (Function A, A9, B, B9) = 3
4-way                  =4
Electromagnetic Directional Valve
path        =6
Graphic Symbols
60~69 series=6X
(The Installation And Connection Dimensions Of The 60 To 69 Series Remain Unchanged)
Spring return  = no mark
No spring return  = no
Without Return Spring, With Positioning Mechanism=OF
Ordinary electromagnet    =E
Wide Voltage Solenoid (only for DC 12V and 24V) = N
24V DC    =G24
220V AC, 50Hz    =W220-50
220V AC system  =W220R
With Manual Emergency Operation Button  =N
❿ Z4=square plug (not applicable to this integral type)
Z5L=square plug with light
ZC=pin type waterproof plug
(Include accessories: plugs, pins, seals)
⓫ No symbol = no throttle plug-in
B08 = Orifice diameter = 0.8mm
B10 = Orifice diameter = 1.0mm
B10 = Orifice diameter = 1.0mm
B15= Orifice diameter = 1.5mm
B20= Orifice diameter = 2.0mm
B25= Orifice diameter =2.5mm
B30= Orifice diameter = 3.0mm
⓬ No sign = Nitrile rubber seal
V=Fluorine rubber seal
